JCB 409 Wheel Loader
Based on the design of the 407, the JCB 409 offers increased power and payload for increased productivity.
Its compact dimensions and low height over cab combined with a pivot-steer design and articulated chassis, provides incredible maneuverability and a tight turning radius. That makes the JCB 409 compact wheel loader indispensable for working in restricted spaces and buildings.
Specifications
| Axle Oscillation | 10.0 degrees |
| Tire Size | 14.5 x 20 |
| Bucket Linkage Type | Parallel |
| Bucket Rollback (Carry) | 53.1 degrees |
| Breakout Force | 12095.0 lbs |
| Bucket Capacity | 1.3 cu yd |
| Bucket Type | General Purpose |
| Bucket Width | 76.0 in |
| Operating Weight | 12830.0 lbs |
| Rated RPM | 2500.0 rpm |
| Engine Torque @RPM | 184.0 ft-lb |
| Gross Horsepower | 75.0 hp |
| Number of Cylinders | 4.0 |
| Horsepower | 72.0 hp |
| Engine Manufacturer | Deutz |
| Displacement | 220.9 cid |
| Fuel Tank Capacity | 21.1 gal |
| Loader Pump Type | Gear |
| Maximum Flow | 20.6 gal/min |
| Operator Protection | EROPS |
| Travel Speed F/R (1st) | 3.8/3.8 mph |
| Travel Speed F/R (2nd) | 12.4/12.4 mph |
| Number of Speeds | 4F/4R |
| Transmission | Hydrostatic |
| Tread Width | 58.0 in |
| Turning Radius (Outside Bucket) | 174.0 in |
| Height to Top of Cab | 104.0 in |
| Height to Hinge Pin | 132.0 in |
| Width Over Tires | 74.0 in |
| Overall Length W/Bucket | 215.0 in |
| Ground Clearance | 18.0 in |
| Wheelbase | 86.0 in |
| Bucket Rollback (Full Height) | 63.6 degrees |
| Dump Height | 174.0 in |
| Dump Reach @ Full Height | 20.0 in |
| Overall Height (Bucket Raised) | 174.0 in |
| Hydraulic Raise Time | 4.9 sec |
| Tipping Load Full Turn | 8628.0 lbs |
| Tipping Load Straight | 10840.0 lbs |
| Total Cycle Time | 11.4 sec |
| Hydraulic Dump Time | 3.5 sec |
| Digging Depth | 2.0 in |
| Articulation Angle | 40.0 degrees |
| Hydraulic Lower Time (Float) | 3.0 sec |
